The near solid appearance allows you to 3D print models or parts with a detailed smooth finish.
Rapid MODEL resin is very versatile and can be printed between 5-micron and 100-micron layer heights. To achieve the best results 3D models should always be designed solid, if hollowing is required, ensure drain holes are included to remove any trapped resin.
Always print large flat areas on an angle to help with print deformation due to the adhesion to the FEP film. To assist with unsupported areas, ensure you use well-positioned, solid supports. This resin will print faster than other resins on the market, please adjust your settings accordingly. Use a calibration model like our Matrix, to dial in your printer with our resin. Check our printer setting page to see if we have your printer listed to give you a good starting point.
Technical Data
All Monocure 3D resins have a very wide range of reactivity, UV wavelengths of 225nm to wavelengths of 420nm. By incorporating a blend of photo-initiators, monomers & sensitizers, almost any UV light source can be used to initiate the polymerisation process of our resins.
Our resins have been tested with a ‘Shore D Hardness Durometer’ and have a rating of 70. (A hard hat has a rating of 80)
The Viscosity of our resin is 500 – 600cps @ 25°C (Brookfield RVT).
All our resins have a low odour, have zero VOC emissions and display very low shrinkage properties <0.5%>
Please store Monocure 3D resin in a dark, cool place out of direct sunlight.
